FEATURES(特性)
1. Rated working voltage range 6.3 to 100V DC/160 to 450V DC at operation temperature
range -40 to +105℃/-25 to+105℃.
额定工作电压范围：6.3~100V DV/160~450V DC，额定工作温度范围：-40~+105℃/-25~+105℃
2.This series is for communication equipments,switching power supply,industrial
measuring instruments,automotive electric products,etc.
该型号系列产品适用于通讯设备、开关电源、工业用测量仪器、汽车电子产品等中
+
-
Safety vent for ф≥6.3
фd±0.05
L + αmax 15min 4min
F±0.5
фD±βmax
Unit：mm
CASE SIZE TABLE(外形图及尺寸表)
5
2.0
6.3
2.5
0.5
8
3.5
10
5.0
12.5
5.0
16
7.5
18
7.5
0.8
22
10.0
25
12.5
0.6 1.0
(L＜20 1.5 (L )2.0
(D＜20)0.5 (D≥20)1.0
) ≥20
фD
F
фd
α
β
PART NUMBER SYSTEM(产品编码)(EXAMPLE:25V330μF)
SPECIFICATIONS
ltem
Operating Temperature Range
Rated Working Voltage Range
Nominal Capacitance Range
Capacitance Tolerance
Leakage Current
Dissipation Factor
tanδ (120Hz,+20℃)
Low Temperature Characteristics
High Temperature Loading
Performance Characteristics
-40 to +105℃
6.3 to 100V
0.1 to 33000μF
±20%（120Hz,+20℃）
I≤0.01CV or 3(
after 2 minuteres application of rated working voltage at +20℃
μA)whichever is greater
-25 to +105℃
160 to 450V
I≤0.03 V + 40(
of rated working voltage at +20
C μA) after 2 minutes application
℃
Working Voltage(V)
tan δ(max.)
6.3
0.26
10
0.22
16
0.18
25
0.16
35
0.14
50
0.12
63
0.10
100
0.08
Working Voltage(V)
tan δ(max.)
160
0.20
200
0.20
220
0.20
250
0.20
350
0.24
400
0.24
420
0.24
450
0.24
For capacitance value＞1000μF,and 0.02 per another 1000μF
Impedance ratio max. at 120Hz
6.3
5
10
Working Voltage (V)
Z-25℃ / Z+20℃
Z-40℃ / Z+20℃
10
4
8
16
3
6
25
2
4
35
2
3
50
2
3
63
2
3
100
2
3
Working Voltage (V)
Z-25℃ / Z+20℃
160
3
200
3
220
3
250
4
350
4
400
6
For capacitance value ℃ / Z+20
Add 1.0 per another 1000μF for Z-40℃ / Z+20℃
＞1000μF,Add 0.5 per another 1000μF for Z-25 ℃
Test conditions
Duraton:
Ambient temp. :105℃
Applied voltage : DC voltage with maximum permissible ripple current specified at +105℃
(Sum of the DC voltage and super-imposed peak AC voltage for maximum persissible ripple
current should be equal to rated DC working voltage).
Post test requirements at +20
Leakage current:≤ Initial specified value
Cap. change : within ±20% of initial measured value
tan δ : ≤200% of initial specified value
℃
+105℃,Standard(标准品)
420
6
450
15
≥10
2000h
фD
Load life
≤8
1000h
Others
Shelf Life
JIS C - 5101 (1EC 60384)
Test conditions
Duration
Ambient temp.
Applied voltage
: 1000 hours
: +105℃
: (None)
Post test requirements at +20
Same limits for high temperature loading.
