description

Very Low Power Consumption
Typical Supply Current . . . 200 μA
(Per Amplifier)
Wide Common-Mode and Differential
Voltage Ranges
Low Input Bias and Offset Currents
Common-Mode Input Voltage Range
Includes VCC+
Output Short-Circuit Protection
High Input Impedance . . . JFET-Input Stage
Internal Frequency Compensation
Latch-Up-Free Operation
High Slew Rate . . . 3.5 V/μs Typ

ordering information
The JFET-input operational amplifiers of the TL06_ series are designed as low-power versions of the
TL08_ series amplifiers. They feature high input impedance, wide bandwidth, high slew rate, and low input offset
and input bias currents. The TL06_ series features the same terminal assignments as the TL07_ and
TL08_ series. Each of these JFET-input operational amplifiers incorporates well-matched, high-voltage JFET
and bipolar transistors in an integrated circuit.
The C-suffix devices are characterized for operation from 0°C to 70°C. The I-suffix devices are characterized
for operation from −40°C to 85°C, and the M-suffix devices are characterized for operation over the full military
temperature range of −55°C to 125°C.
