盛群HOLTEK-HT7130-1 HT7150-1 HT7133-1 HT71XXA-1系列特价供应
当 前 价：电议
起订数量： /
供货总量： /
有效期至： 2012年12月12日
| 品牌 | HOLTEK 合泰 盛群 | 型号 | HT7130A-1 |
| 批号 | 10+ | 封装 | SOT89 TO92 |
| 营销方式 | 厂家直销 | 产品性质 | 热销 |
| 处理信号 | 数字信号 | 制作工艺 | 半导体集成 |
| 导电类型 | 双极型 | 集成程度 | 大规模 |
| 工作温度 | -40~85（℃） | 类型 | 稳压IC |
原厂正品特价供应,价格面议!
HT71XX-1 -- 30mA Low Power LDO
General Description
The HT71XX-1 series is a set of three-terminal low power high voltage regulators implemented in CMOS technology. They allow input voltages as high as 24V. They are available with several fixed output voltages ranging from 2.1V to 5.0V. CMOS technology ensures low voltage drop and low quiescent current.
Although designed primarily as fixed voltage regulators, these devices can be used with external components to obtain variable voltages and currents.
Features - Low power consumption
- Low voltage drop
- Low temperature coefficient
- High input voltage (up to 24V)
- Output voltage accuracy: tolerance ± 3%
- TO92, SOT89 and SOT23-5 package
|
HT71XX-1 TinyPowerTMLDO
| Part No. | Maximum
Input Voltage | Output Voltage | Typical Output
Current (mA) | Typical Current
Consumption (µA) | Tolerance | Package |
| HT1015-1 | 12V | 1.5V | 18 | 2.2 | ± 3% | TO92, SOT23-5, SOT89 |
| HT7121-1 | 24V | 2.1V | 30 | 2.5 | ± 3% | TO92, SOT23-5, SOT89 |
| HT7123-1 | 24V | 2.3V | 30 | 2.5 | ± 3% | TO92, SOT23-5, SOT89 |
| HT7125-1 | 24V | 2.5V | 30 | 2.5 | ± 3% | TO92, SOT23-5, SOT89 |
| HT7127-1 | 24V | 2.7V | 30 | 2.5 | ± 3% | TO92, SOT23-5, SOT89 |
| HT7130-1 | 24V | 3.0V | 30 | 2.5 | ± 3% | TO92, SOT23-5, SOT89 |
| HT7133-1 | 24V | 3.3V | 30 | 2.5 | ± 3% | TO92, SOT23-5, SOT89 |
| HT7136-1 | 24V | 3.6V | 30 | 2.5 | ± 3% | TO92, SOT23-5, SOT89 |
| HT7144-1 | 24V | 4.4V | 30 | 2.5 | ± 3% | TO92, SOT23-5, SOT89 |
| HT7150-1 | 24V | 5.0V | 30 | 2.5 | ± 3% | TO92, SOT23-5, SOT89 |
